Bucket Teeth by Machine Family: Part Numbers and Pin Sizes
Three naming systems cover most of the machines our customers run, and the pin is what identifies the tooth in all of them. Cat numbers a family by size (J200 to J400) and then a profile inside it; Komatsu numbers the machine family itself; Volvo uses the same figure for the tooth family and for the machine, so a "210" tooth and an EC210 tooth are two different parts; Hyundai went the other way and kept one machine badge across two tooth generations, so an R210 can carry a 4.50 kg, a 5.80 kg or a 6.50 kg point. Here are the numbers we quote most often, with the pin that has to come with them.
| Machine family | Tooth number (standard long) | Pin | Pin size | Retainer |
|---|---|---|---|---|
| Cat J200 class | 1U-3202 | 8E-6208 (groove pin) | 11 mm × 61 mm | 8E-6209 (22 mm) |
| Cat J250 class (307 / 311 / 312) | 1U-3252 | 132-4763 (heavy duty) | 14 mm × 78 mm | 149-5733 (30 mm) |
| Cat J300 class | 1U-3302 | 132-4766 / 9J-2308 | 14 mm × 92 mm | 149-5733 / 8E-6259 |
| Cat J350 class | 1U-3352 | 114-0358 | 19 mm × 108 mm | 114-0359 (40 mm) |
| Komatsu PC200 / PC220 / PC240 | 205-70-19570 | 092-44-02496 | Komatsu PC200 pin | Snap-ring type on the pin |
| Komatsu PC300 / PC350 / PC360 | 207-70-14151 standard / RC rock / TL tiger | 09244-02516 (175-78-21810) | 25 mm × 120 mm, 27 mm head | Snap-ring on the pin; weld-on adapter 207-939-3120 in 40 / 45 / 50 / 55 mm gap |
| Komatsu PC200 weld-on adapter | 20Y-70-14520 shank for the 205-70-19570 tooth | 092-44-02496 (same pin as the tooth) | About 1 1/4 in (32 mm) lip class per one US dealer | Parts-book weight 6.750 kg / 8.25 kg; 205-939-7120 quoted as 30 / 35 / 40 mm gap |
| Hitachi ZX200 / ZX210 class | 4427919 (35S) or 205-70-19570 | 4501627 (35PN) or 092-44-02496 | Top pin on the 35S point; side pin on the 205-70-19570 style | 4501625 (35-40LK) rubber lock with the 35PN pin |
| Hitachi EX200 / EX210 class | TB00705 standard / TB00705RC rock | EX210PN (pin and retainer) | Top lock pin through the tooth, on the TB00704 weld-on two-strap adapter (40 mm gap) | Not the ZX200 tooth - 35S (4427919) and 205-70-19570 do not interchange. Side cutters 2014503 / 2014504 are shared |
| Doosan DH220-5 / S220-5 / DX225 / DX225LC / DX225LCA | 2713-1217 standard / 2713-1217RC rock / 2713-1217TL tiger | 2705-1020 (also written 2705-9012) | 19-20 mm × 105 mm, quoted at 0.26-0.30 kg | 2114-9008 (also 2114-1848); weld-on adapter 2713-1218 in a 35 / 40 mm gap (3T1218 is the 35 mm number) |
| Doosan DH280 / DH300 / S290-5 class (the contrast case) | 2713-1219 (also written 230111-00090 / 713-00054) | 2705-9010 | 22 mm × 109 mm, about 0.35-0.4 kg | 2114-1849; adapter 2713-1220 in 40 / 50 mm gaps. Full DH300 / DX300 guide. Some catalogue pages list this tooth for the DX225LCA as well - the pin diameter is the tiebreaker |
| Doosan DH360 / DH370 / S330 class (the big-bucket contrast case) | 2713-0032 (also written 713-00032 / 2713-00032 / 2713-1234; RC = 713-00032RC, TL = 713-00032TL) | 2705-1021 with lock 2114-1849, or 705-00006 with retainer 114-00246 | Quoted 23 × 137 mm in the cross-reference tables and 24 × 130 mm on a supplier page; we ask for the caliper reading rather than print a diameter we cannot confirm | Adapter 2713-0033 (6.2 cm) / 713-00033 in 40 / 50 / 55 / 60 mm openings. Some rows print retainer 8E8409 - that is Caterpillar's J400 retainer. Full DH360 / DX380 guide |
| Volvo EC210 / EC210C / EC220D / EW205D ("Volvo 210" family) | 14530544 (also written 1453-0544, cross-referenced to 1171-01371); RC = 14530544RC / 1171-00371RC, TL = 14530544TL. Quoted 6.6-7.2 kg standard | 14540726 (1454-0726), about 0.26 kg | Catalogue pages quote tooth weights for this family, not pin dimensions - caliper the pin you pulled. Listings that show 8E6358 / 8E6359 are printing the Caterpillar J350 pin and retainer, not the Volvo part | Retainer 14537622 (1453-7622); adapter 1171-01620 (40 mm opening), with 14530543 / 14400986 at 11.30 kg and the bevel 14732592 at 11.70 kg in the same opening. Side cutters 14652623 / 14652622 at 12.70 kg. Full EC210 guide |
| Volvo EC / EW210 in the factory parts guide (the small-tooth row) | 20GPE / VOE 1542685 at 4.5 kg, with 20MRE 1542675, 20PPE 1542793, 20TPE 15431283 and 20NSE 15431281 in the same row; heavier option 30GPE 15423552 at 6.7 kg | Locking device 20PX / VOE 11417146 (0.1 kg) on the 20-series row, 30PX / VOE 11417147 on the heavier row | 15J20R / VOE 11417161 standard and 15J20MR / VOE 11716119 heavy duty on the 20-series row; 30J40R 11417171 and 30J40MR 11716120 on the heavier one; fitting tool 15J30T / VOE 11417168 | Adapter AE02BL40 - VOE 1542961 at 10.4 kg (long bottom leg) or VOE 1542962 at 12.5 kg. A 4.5 kg tooth and a 6.7 kg tooth are both sold as an EC210 tooth, so weigh the one you are replacing before you order a set |
| Hyundai R210 / R220 / R235 / R225-9 (the heavy end of the class) | 61Q6-31310 (also written 61Q631310); RC = 61Q6-31310RC, TL = 61Q6-31310TL, twin tiger = 61Q6-31310WT. Quoted 6.50 kg standard / 6.20 kg RC / 5.70 kg TL. The -7 generation is filed under 61N6-31310 at 5.80 kg in some catalogues and under 61Q6-31310 in others | E161-3035, quoted at 0.23 kg | Catalogues print weights for this family, not pin dimensions - caliper the pin you pulled. The same E161-3035 is published for the lighter 4.50 kg E161-3027 tooth, so the pin does not identify the system | Retainer 61E5-11150 at 0.05 kg; adapter 61Q6-31320 in a 35 mm opening (10.00 kg) or a 32 mm bevel (9.80 kg), with the earlier E161-3017 nose published at 35 mm and 40 mm. Side cutters 63E1-3533 / 63E1-3534 at 20.80 kg, R215 rows 63E1-3533C / 63E1-3534C at 18.10 kg. Full R210 / R220 guide |
| Hyundai R200 / R210 class and the 5-tooth rock bucket | E161-3027 (also written E1613027) at 4.50 kg standard / 4.80 kg RC / 6.10 kg TL; the rock bucket instead runs 61N8-31310GG with 61N8-31310 quoted at 9.00 kg and 61N8-31310TL at 10.00 kg | E161-3035 at 0.23 kg on all three standard systems; the rock system switches to E262-5004 at 0.26 kg | Fitment rows put the 61N8 rock point on the R210LC-9 and R210LC-9BC, and on the HW210, HX220L, HX235LCR, HX260L, R220LC-9, R250LC-7 and R290LC-7 - a 9 kg tooth on a 21-tonne machine, because the bucket is the rock option | Retainer 61E5-11150 (0.05 kg) on every row including the rock system; adapters E161-3017 at 35 mm (9.80 kg), 40 mm (9.10 kg) and 35 mm bevel (7.40 kg), and 61N8-31320 at 40 mm (13.8 kg) on the rock bucket. Full R210 / R220 guide |
Profiles sit inside each family and share the pin: 1U-3251 (short), 1U-3252RC (rock chisel), 9J-4259 (penetration) all run on the J250 hardware; 205-70-19570RC (rock chisel) and 205-70-19570TL (tiger long) run on the same 092-44-02496 as the PC200 standard tooth. Mixed boxes therefore need only one pin number, which is why we quote teeth, pins and retainers as one line rather than three.
We do not publish prices on this page. What a container of teeth costs depends on the profile mix, the quantity of pins and retainers, the grade of casting and the shipping lane. Send the machine model with serial prefix, the tooth number or a photo of the old tooth, and the pin measurement, and we come back with a firm quote — FOB Shanghai or CIF to your port.
FAQ
Q: How do I know which bucket tooth size my excavator takes?
A: Measure the pin. J200 is an 11 mm pin at 61 mm long; J225, J250 and J300 share a 14 mm pin at 69, 78 and 92 mm; J350 steps up to 19 mm at 108 mm. Retainers confirm it — Cat describes 149-5733 as a 14 mm J300 pin retainer. On the Komatsu side the tooth number names the machine instead: the PC200 standard tooth is 205-70-19570 and always takes pin 092-44-02496.
Q: Are aftermarket bucket teeth as good as OEM?
A: Aftermarket teeth reproduce the OEM envelope — pin, pocket and adapter nose — which is what makes them fit. What varies between suppliers is the casting grade and heat treatment. Suppliers in this family normally quote 48–52 HRC with an impact value above 20 J. Ask for those two figures in writing and trial a set before you commit a container to a foundry you have not used.
Q: Can I fit Cat J-series teeth on a Komatsu bucket?
A: No. Different pins, different pockets, different nose angles. A J250 tip takes a 78 mm × 14 mm pin on a J250 weld-on adapter such as 119-3253 or 1U-0257; a Komatsu PC200 tooth takes 092-44-02496 on a Komatsu-style adapter such as 20Y-70-14520 or 205-939-7120. Teeth that look alike in a photo are not interchangeable across brands.
